Weber 3000 Owner's Manual

15
Step 13
Install side burner
You will need: side burner assembly, burner grate, and
manifold bracket.
WARNING: Make sure gas supply is OFF.
Slide the side burner assembly into the open end of the
right frame. Route the side burner hose around the tank
panel so it will not interfere with scale indicator rod.
The side burner hose is connected in the following
manner:
Slide back the collar of the quick disconnect on the
manifold. Push the male fitting of the side burner hose into
the quick disconnect, and maintain pressure. Slide the
collar closed. Figure 14a. Figure 14b shows the quick
disconnect engaged.
Install burner grate. Check to be sure the side burner
valve is OFF. Push side burner control knob down and
turn clockwise. Figure 14.
Step 14
Install manifold bracket
You will need: manifold bracket
Hook the bracket onto the manifold at the center burner
valve. Figure 15. Place your hand underneath the bracket.
Lift the bracket, manifold and cooking box slightly as a unit
and hook onto the frame brace.
Figure 15
Figure 14
Frame brace
Manifold bracket
Manifold side view
Manifold side view
Male fitting
of side burner
Quick disconnect
engaged
Side burner hose
b)
a)

Weber 3000 Specifications

General

Burners	3
Ignition	Electronic
Fuel Type	Propane
BTU Output	30, 000 BTU/hour
Category	Gas Grill
