Weber Summit PLATINUM D4 - Manifold Assembly Removal

29 29
9. Disconnect the Thermocouple from the IR Burner valve. 10. Remove screws from the manifold assembly: (a) Locate the screws on
both sides of the manifold frame.
(b) Remove the screws from manifold frame.
D4
D6
(b)
(a)
(b)
(a)
(b)
(b)
(a)
(a)
D4
D6
MAINTENANCE
