Weber Summit PLATINUM D4 - Burner Assembly Procedures

30
11. Pull manifold assembly out from the manifold frame. 12. Lift and twist the burner assembly slightly, to separate the Crossover
®
tube (a) from the burners (b).
13. Remove the Crossover
®
tube.
14. Pull the selected burner(s) tube(s) from manifold frame and replace
with a new burner tube.
D4
D6
A
B
B
MAINTENANCE
