91
CHAPTER 9 - TECHNICAL SPECIFICATIONS
9.2 ELECTRONIC/GENERAL DATA
Applied Voltage V/F (scalar)
0 to 300Hz, resolution: 0,01Hz.
Speed regulation: 1% of the rated speed.
1 isolated input, resolution: 7 bits, (0 to 10)V or (0 to 20)mA, or
(4 to 20)mA
Impedance: 100kΩ [(0 to 10)V], 500 [(0 to 20)mA or
(4 to 20)mA], programable function
4 isolated digital inputs, 12V dc, programmable functions
1 relay with reverse contacts, 240V ac, 0.5A, programmable
functions
Overcurrent/output short-circuit
Undervoltage and overvoltage at the power part
Inverter overtemperature
Motor/inverter overload (IxT)
External fault
Programming error
Defective inverter
4 keys: start, stop, increment, decrement and Programming,
LEDs display: 3 digits with 7 segments
LEDs for Parameter and its Contecnt Indication
It permits access/alteration of all parameters
Display accuracy:
- current: 10% of the rated current
- Voltage resolution: 1 V
- frequency resolution: 0,1Hz
For all models
Inverters and semicondutors
Power Conversion Equipment
Electronic equipment for use in power installations
Safety requirements for electrical equipment for measurement,
control and laboratory use
EMC product standard for adjustable speed electrical power drive
systems, with external filter
METHOD
CONTROL OUTPUT
FREQUENCY
PERFORMANCE V/F Control
INPUTS ANALOG
(CC10 Board)
DIGITAL
OUTPUT RELAY
(CC10 Board)
SAFETY PROTECTION
KEYPAD STANDARD HMI
(HMI)
DEGREE OF IP20
PROTECTION
IEC 146
UL 508 C
STANDARDS EN 50178
EN 61010
EN 61800-3
