CFW-10 - QUICK PARAMETER REFERENCE
Software: V1.0X
Application:
Model:
Serial Number:
Responsible:
Date: / / .
QUICK PARAMETER REFERENCE, FAULT AND STATUS MESSAGES
I. Parameters
Parameter Function
Adjustable Range
Factory
Unit User Setting Page
Setting
P000 Parameter Access
0 to 4, 6 to 999 = Read
0- 55
5 = Alteration
READ ONLY PARAMETERS (P002 to P099)
P002
Fequency Proportional Value
0 to 6553 - - 55
(P208xP005)
P003 Motor Current (output) 0 to 1.5xInom - A 55
P004 DC Link Voltage 0 to 524 - V 55
P005 Motor Frequency (output) 0.00 to 99.9, 100 to . 300 - Hz 55
P007 Motor Voltage (output) 0 to 524 - V 55
P008 Heatsink Temperature 25 to 110 - ºC 55
P014 Last Fault 00 to 41 - - 55
P023 Software Version x . y z - - 55
REGULATION PARAMETERS (P100 to P199)
Ramps
P100 Acceleration Time #1 0.1 to 999 5.0 s 56
P101 Deceleration Time #1 0.1 to 999 10.0 s 56
P102 Acceleration Time #2 0.1 to 999 5.0 s 56
P103 Deceleration Time #2 0.1 to 999 10.0 s 56
P104
0 = Inactive
0% 56
S Ramp 1 = 50
2 = 100
Frequency Reference
P120 Digital Reference Backup
0 = Inactive
1 = Active 1 - 57
2 = Backup by P121
P121 Keypad Frequency Reference P133 to P134 3.00 Hz 57
P122 JOG Speed Reference P133 to P134 5.00 Hz 57
P124 Multispeed Reference 1 P133 to P134 3.00 Hz 58
P125 Multispeed Reference 2 P133 to P134 10.00 Hz 58
P126 Multispeed Reference 3 P133 to P134 20.00 Hz 58
P127 Multispeed Reference 4 P133 to P134 30.00 Hz 58
P128 Multispeed Reference 5 P133 to P134 40.00 Hz 58
P129 Multispeed Reference 6 P133 to P134 50.00 Hz 58
P130 Multispeed Reference 7 P133 to P134 60.00 Hz 58
P131 Multispeed Reference 8 P133 to P134 66.00 Hz 58
Speed Limits
P133 Minimum Frequency (F
min
) 0.00 to P134 3.0 Hz 59
P134 Maximum Frequency (F
max
) P133 to 300Hz 66.0 Hz 59
