Functions Common to all the Control Modes

11-6 | CFW501

rated

DC link voltage (P0004)

F0022-

Overvoltage

DC link

regulation

Time

P0151

Output

speed

Figure 11.3: Example graph of DC link voltage limitation – Ramp Hold (P0152 = 0 or P0152 = 2)

Ramp

Reference

Output speed

Error

P0001

P0004

P0151

P0152

P0152 x error

P0002

P0100-P0104

Figure 11.4: Block diagram of DC link voltage limitation – Accelerate Ramp (P0152 = 1 or P0152 = 3)
