WEG CFW501 V1.8X User Manual

Quick Reference of Parameters, Alarms and Faults
0-2 | CFW501
0
Param. Function Adjustable Range Factory Setting
User
Setting
Propr. Groups Pag.
P0029 Power HW Config.
0 = Not Identified
1 = 200-240 V / 1.6 A
2 = 200-240 V / 2.6 A
3 = 200-240 V / 4.3 A
4 = 200-240 V / 7.0 A
5 = 200-240 V / 9.6 A
6 = 380-480 V / 1.0 A
7 = 380-480 V / 1.6 A
8 = 380-480 V / 2.6 A
9 = 380-480 V / 4.3 A
10 = 380-480 V / 6.1 A
11 = 200-240 V / 7.3 A
12 = 200-240 V / 10.0 A
13 = 200-240 V / 16.0 A
14 = 380-480 V / 2.6 A
15 = 380-480 V / 4.3 A
16 = 380-480 V / 6.5 A
17 = 380-480 V / 10.0 A
18 = 200-240 V / 24.0 A
19 = 380-480 V / 14.0 A
20 = 380-480 V / 16.0 A
21 = 500-600 V / 1.7 A
22 = 500-600 V / 3.0 A
23 = 500-600 V / 4.3 A
24 = 500-600 V / 7.0 A
25 = 500-600 V / 10.0 A
26 = 500-600 V / 12.0 A
27 = 200-240 V / 28.0 A
28 = 200-240 V / 33.0 A
29 = 380-480 V / 24.0 A
30 = 380-480 V / 31.0 A
31 = 500-600 V / 17.0 A
32 = 500-600 V / 22.0 A
33 = 200-240 V / 47.0 A
34 = 200-240 V / 56.0 A
35 = 380-480 V / 39.0 A
36 = 380-480 V / 49.0 A
37 = 500-600 V / 27.0 A
38 = 500-600 V / 32.0 A
ro READ 6-2
P0030 Heatsink Temperature -20 to 150 ºC ro READ 15-5
P0037 Motor Overload Ixt 0 to 100 % ro READ 14-3
P0042 Powered Time 0 to 65535 h ro READ 15-5
P0043 Enabled Time 0.0 to 6553.5 h ro READ 15-5
P0044 kWh Output Energy 0 to 65535 kWh ro READ 15-6
P0047 CONF State 0 to 999 ro READ 15-6
P0048 Present Alarm 0 to 999 ro READ 14-8
P0049 Present Fault 0 to 999 ro READ 14-8
P0050 Last Fault 0 to 999 ro READ 14-8
P0051 Current At Last Fault 0.0 to 200.0 A ro READ 14-9
P0052 DC Link At Last Fault 0 to 2000 V ro READ 14-9
P0053 Frequency At Last Fault 0.0 to 500.0 Hz ro READ 14-9
P0054 Temp. At Last Fault -20 to 150 ºC ro READ 14-10
P0055 Log. State Last Fault 0000h to FFFFh ro READ 14-10
P0060 Second Fault 0 to 999 ro READ 14-8
P0061 Current at 2
nd
Fault 0.0 to 200.0 A ro READ 14-9
P0062 DC Link at 2
nd
Fault 0 to 2000 V ro READ 14-9
P0063 Frequency 2
nd
Fault 0.0 to 500.0 Hz ro READ 14-9
P0064 Temp. 2
nd
Fault -20 to 150 ºC ro READ 14-10
P0065 Log. State 2
nd
Fault 0000h to FFFFh ro READ 14-10
P0070 Third Fault 0 to 999 ro READ 14-8
P0071 Current at 3
rd
Fault 0.0 to 200.0 A ro READ 14-9
P0072 DC Link 3
rd
Fault 0 to 2000 V ro READ 14-9
P0073 Frequency 3
rd
Fault 0.0 to 500.0 Hz ro READ 14-9
P0 074 Temp. 3
rd
Fault -20 to 150 ºC ro READ 14-10
