Quick Reference of Parameters, Alarms and Faults
CFW501 | 0-3
0
Param. Function Adjustable Range Factory Setting
User
Setting
Propr. Groups Pag.
P0075 Log. State 3
rd
Fault 0000h to FFFFh ro READ 14-10
P0080 Last Fault in “Fire Mode” 0 to 999 0 ro READ 14-10
P0081 Second Fault in “Fire Mode” 0 to 999 0 ro READ 14-10
P0082 Third Fault in “Fire Mode” 0 to 999 0 ro READ 14-10
P0100 Acceleration Time 0.1 to 999.0 s 10.0 s BASIC 11-1
P0101 Deceleration Time 0.1 to 999.0 s 10.0 s BASIC 11-1
P0102 2
nd
Ramp Accel. Time 0.1 to 999.0 s 10.0 s 11-2
P0103 2
nd
Ramp Decel. Time 0.1 to 999.0 s 10.0 s 11-2
P0104 S Ramp 0 = Inactive
1 = Active
0 cfg 11-2
P0105 1
st
/2
nd
Ramp Sel. 0 = 1
st
Ramp
1 = 2
nd
Ramp
2 = DIx
3 = Serial/USB
4 = SoftPLC
2 I/O 11-3
P0106 3
rd
Ramp Time 0.1 to 999.0 s 5.0 s 11-3
P0120 Speed Ref. Backup 0 = Inactive
1 = Active
2 = Backup by P0121
1 7-8
P0121 Keypad Reference 0 to 18000 rpm 90 rpm 7-9
P0122 JOG Reference 0 to 18000 rpm 150 (125) rpm 7-9
P0133 Minimum Speed 0 to 18000 rpm 90 (75) rpm BASIC 7-8
P0134 Maximum Speed 0 to 18000 rpm 1800 (1500) rpm BASIC 7-8
P0135 Max. Output Current 0.0 to 200.0 A 1.5xI
nom
V/f, V V W BASIC,
MOTOR
11-8
P0136 Manual Torque Boost 0.0 to 30.0 % According to
inverter model
V/f BASIC,
MOTOR
9-4
P0137 Autom. Torque Boost 0.0 to 30.0 % 0.0 % V/f MOTOR 9-6
P0138 Slip Compensation -10.0 to 10.0 % 0.0 % V/f MOTOR 9-7
P0139 Output Current Filter 0 to 9999 ms 50 ms 8-1
P0140 Sleep Compensation Filter 0 to 9999 ms 500 ms VVW 8-2
P0142 Max. Output Voltage 0.0 to 100.0 % 100.0 % cfg, V/f 9-5
P0143 Interm.Output Voltage 0.0 to 100.0 % 66.7 % cfg, V/f 9-5
P0144 Low Output Voltage 0.0 to 100.0 % 33.3 % cfg, V/f 9-5
P0145 Field Weakening Speed 0 to 18000 rpm 1800 (1500) rpm cfg, V/f 9-5
P0146 Intermediate Speed 0 to 18000 rpm 1200 (1000) rpm cfg, V/f 9-5
P0147 Low Speed point 0 to 18000 rpm 600 (500) rpm cfg, V/f 9-5
P0150 Ud Regul. Type V/f and Current
Limitation
0 = hold_Ud and desac_LC
1 = acel_Ud and desac_LC
2 = hold_Ud and hold_LC
3 = acel_Ud and hold_LC
0 cfg, V/f,
VVW
MOTOR 11-4
P0151 DC Regul. Level V/f 339 to 1200 V 400 V (P0296 = 0)
800 V (P0296 = 1)
1000 V (P0296 = 2)
V/f, V V W MOTOR 11- 5
P0152 DC Link Regul. P Gain 0.00 to 9.99 1.50 V/f, V V W MOTOR 11- 5
P0153 Dyn. Braking Level 339 to 1200 V 375 V (P0296 = 0)
750 V (P0296 = 1)
950 V (P0296 = 2)
V/f, V V W MOTOR 13-1
P0156 Overl.Curr. 100 % Speed 0.0 to 200.0 A 1.1xI
nom
MOTOR 14-2
P0157 Overl.Curr. 50 % Speed 0.0 to 200.0 A 1.0xI
nom
MOTOR 14-2
P0158 Overl.Curr. 20 % Speed 0.0 to 200.0 A 0.8xI
nom
MOTOR 14-2
P0178 Rated Flux 0.0 to 150.0 % 100.0 % MOTOR 10-4
P0200 Password 0 = Inactive
1 = Active
1 to 19999 = New password
0 HMI 5-3
P0202 Type of Control 0 to 2 = V/f
3 = V VW
0 cfg STARTUP 8 -1
To Next Page
