WEG CFW501 V1.8X User Manual

Quick Reference of Parameters, Alarms and Faults
0-4 | CFW501
0
Param. Function Adjustable Range Factory Setting
User
Setting
Propr. Groups Pag.
P0204 Load/Save Parameters 0 to 2 = Not Used
3 = Reset P0043
4 = Reset P0044
5 = Load 60 Hz
6 = Load 50 Hz
7 = Load User 1
8 = Load User 2
9 = Save User 1
10 = Save User 2
11 = Load SoftPLC
12 to 15 = Reserved
0 cfg 5-11
P0205 Main Parameter Display 0 to 1079 2 HMI 5-3
P0206 Secondary Parameter Display 0 to 1079 1 HMI 5-3
P0208 Main Display Scale Factor 0.1 to 1000.0 % 100.0 % HMI 5-4
P0209 Main Display Eng. Unit 0 = None
1 = V
2 = A
3 = rpm
4 = s
5 = ms
6 = None
7 = m
8 = None
9 = None
10 = %
11 = ºC
12 = None
13 = Hz
14 = None
15 = h
16 = W
17 = kW
18 = None
19 = None
20 = min
21 = °F
22 = bar
23 = mbar
24 = psi
25 = Pa
26 = kPa
27 = MPa
28 = mwc
29 = mca
30 = gal
31 = l
32 = in
33 = ft
34 = m
3
35 = ft
3
36 = gal/s
37 = gal/min
38 = gal/h
39 = l/s
40 = l/min
41 = l/h
42 = m/s
43 = m/min
44 = m/h
45 = ft/s
46 = ft/min
47 = ft/h
48 = m
3
/s
49 = m
3
/min
50 = m
3
/h
51 = ft
3
/s
52 = ft
3
/min
53 = ft
3
/h
54 = According to P0510
55 = According to P0512
56 = None
57 = According to P0516
3 HMI 5-5
