Basic Instructions for Programming and Settings
5-2 | CFW501
5
NOTE!
Besides the selected group in the menu field of the HMI, the view of the parameters on the HMI
depends on the hardware installed and on the operating mode of the CFW501. Therefore, observe
the connected plug-In module, as well as the motor control mode: VVW or V/f. For example, if the
plug-in module only features the analog input AI1, the parameters related to the other analog inputs
are not shown. The same occurs with the parameters exclusively related to the VVW and V/f modes.
5.3 HMI
In the HMI group, you find parameters related to the showing of information on the display, backlight and password
of the HMI. See detailed description below of the possible settings of the parameters.
P0000 – Access to the Parameters
Adjustable
Range:
0 to 9999 Factory
Setting:
0
Description:
Password input to release the access to the parameters. Once a password is saved in P0200, the access to
the parameters is only allowed if this password is set in P0000.
After setting P0000 with a password value, P0000 will show “1” or “0”, keeping the set password value hidden.
Where “1” releases the access to parameters and “0” locks the access to the parameters.
NOTE!
The access to the parameters and P0000 is cleared together with the powering down of the inverter.
