P0029 – Power Hardware Configuration
Adjustable
Range:
0 to 38 Factory
Setting:
Properties: ro
Access groups
via HMI:
READ
Description:
This parameter identifies the inverter model, distinguishing frame, supply voltage and rated current as per Table 6.2:
Identification of the CFW501 models for frames A, B, C, D and E on page 6-2.
From P0029, the CFW501 determines the current and voltage parameters which depend on the identification of the
model. On the other hand, this action is only executed at the moment the factory default is loaded (P0204 = 5 or 6).
Table 6.2: Identification of the CFW501 models for frames A, B, C, D and E
Voltage Power Supply Current Frame P0029
- - - - 0
200-240 V Single-Phase or Mono/Tri 1.6 A A 1
200-240 V Single-Phase or Mono/Tri 2.6 A A 2
200-240 V Single-Phase or Mono/Tri 4.3 A A 3
200-240 V Single-Phase or Three-Phase 7. 0 A A 4
200-240 V Three-Phase 9.6 A A 5
380-480 V Three-Phase 1.0 A A 6
380-480 V Three-Phase 1.6 A A 7
380-480 V Three-Phase 2.6 A A 8
380-480 V Three-Phase 4.3 A A 9
380-480 V Three-Phase 6.1 A A 10
200-240 V Single-Phase or Three-Phase 7. 3 A B 11
200-240 V Single-Phase or Three-Phase 10.0 A B 12
200-240 V Three-Phase 16.0 A B 13
380-480 V Three-Phase 2.6 A B 14
380-480 V Three-Phase 4.3 A B 15
380-480 V Three-Phase 6.5 A B 16
380-480 V Three-Phase 10.0 A B 17
200-240 V Three-Phase 24.0 A C 18
380-480 V Three-Phase 14.0 A C 19
380-480 V Three-Phase 16.0 A C 20
500-600 V Three-Phase 1.7 A C 21
500-600 V Three-Phase 3.0 A C 22
500-600 V Three-Phase 4.3 A C 23
500-600 V Three-Phase 7.0 A C 24
500-600 V Three-Phase 10.0 A C
25
500-600 V Three-Phase 12.0 A C 26
200-240 V Three-Phase 28.0 A D 27
200-240 V Three-Phase 33.0 A D 28
380-480 V Three-Phase 24.0 A D 29
380-480 V Three-Phase
31.0 A D 30
500-600 V Three-Phase 17.0 A D 31
500-600 V Three-Phase 22.0 A D 32
200-240 V Three-Phase
47.0 A E 33
200-240 V Three-Phase
56.0 A E 34
380-480 V Three-Phase
39.0 A E 35
380-480 V Three-Phase
49.0 A E 36
500-600 V Three-Phase 27.0 A E 37
500-600 V Three-Phase 32.0 A E 38
