WEG CFW501 V1.8X User Manual

0
Quick Reference of Parameters, Alarms and Faults
CFW501 | 0-1
0
QUICK REFERENCE OF PARAMETERS, ALARMS AND FAULTS
Param. Function Adjustable Range Factory Setting
User
Setting
Propr. Groups Pag.
P0000 Access to Parameters 0 to 9999 0 5-2
P0001 Speed Reference 0 to 65535 rpm ro READ 15-1
P0002 Motor Speed 0 to 65535 rpm ro READ 15-1
P0003 Motor Current 0.0 to 200.0 A ro READ 15-1
P0004 DC Link Voltage (Ud) 0 to 2000 V ro READ 15-1
P0005 Motor Frequency 0.0 to 500.0 Hz ro READ 15-2
P0006 VFD Status 0 = Ready
1 = Run
2 = Undervoltage
3 = Fault
4 = Self-Tuning
5 = Configuration
6 = DC-Braking
7 = Reserved
8 = Reserved
9 = Reserved
ro READ 15-2
P0007 Output Voltage 0 to 2000 V ro READ 15-3
P0009 Motor Torque -1000.0 to 1000.0 % ro READ 15-3
P0010 Output Power 0.0 to 6553.5 kW ro READ 15-3
P0 011 Power Factor -1.00 to 1.00 ro READ 15-3
P0012 DI8 to DI1 Status Bit 0 = DI1
Bit 1 = DI2
Bit 2 = DI3
Bit 3 = DI4
Bit 4 = DI5
Bit 5 = DI6
Bit 6 = DI7
Bit 7 = DI8
ro READ, I/O 12-16
P0013 DO5 to DO1 Status Bit 0 = DO1
Bit 1 = DO2
Bit 2 = DO3
Bit 3 = DO4
Bit 4 = DO5
ro READ, I/O 12-22
P0014 AO1 Value 0.0 to 100.0 % ro READ, I/O 12-7
P0015 AO2 Value 0.0 to 100.0 % ro READ, I/O 12-7
P0016 FO % Value 0.0 to 100.0 % ro READ, I/O 12-13
P0017 FO Hz Value 0 to 20000 Hz ro READ, I/O 12-13
P0018 AI1 Value -100.0 to 100.0 % ro READ, I/O 12-1
P0019 AI2 Value -100.0 to 100.0 % ro READ, I/O 12-1
P0020 AI3 Value -100.0 to 100.0 % ro READ, I/O 12-1
P0021 FI % Value -100.0 to 100.0 % ro READ, I/O 12-11
P0022 FI Hz Value 0 to 20000 Hz ro READ, I/O 12-11
P0023 Main SW Version 0.00 to 655.35 ro READ 6-1
P0024 Sec. SW Version 0.00 to 655.35 ro READ 6-1
P0027 Plug-In Mod. Config. 0 = No Plug-in
1 to 8 = Reserved
9 = CFW500-CRS485
ro READ 6-1
