SoftPLC
17-2 | CFW501
17
P1003 – SoftPLC Applicative Selection
Adjustable
Range:
0 = User
1 = HVAC
Factory
Setting:
1
Properties: cfg
Access groups
via HMI:
HVAC
Description:
It allows the user to select the CFW501 built in applications.
Table 17.1: Parameter P1003 option description
P1003 Description
0
It defines that the application to be executed on the SoftPLC is the one uploaded by the user by means of the
“WLP” programming tool or flash memory module “CFW500-MMF”.
1
It defines that the application to be executed on the SoftPLC is the HVAC. Refer to chapter 18 HVAC FUNCTIONS
on page 18-1 for further details.
NOTE!
One part of the HVAC functions is directly implemented on the CFW501 firmware and the other part
on the SoftPLC program; in this case the related parameters are in the range starting from P1010.
Thus, by setting P1003 = 0, those functions on SoftPLC will be discarded.
For further information about the user’s application on the CFW501, refer to the SoftPLC manual.
P1010 to P1079 – SoftPLC Parameters
Adjustable
Range:
-32768 to 32767 Factory
Setting:
0
Properties:
Access groups
via HMI:
HVAC
Description:
They are composed of parameters with use defined by the application selected on parameter P1003.
P1010 – Version of the HVAC Functions
Adjustable
Range:
0.00 to 100.00 Factory
Setting:
Properties: ro
Access groups
via HMI:
HVAC
Description:
It indicates the version of the HVAC applicative resident on the CFW501.
