14.1.3 Beverage selection code table

DESCRIPTION SIGNAL RELAY I/O CONNECTOR REF.

1 GR1 Espresso 011 h 1 CN7-1

1 GR1 Medium 012 h 2 CN7-2

1 GR1 Large 013 h 3 CN7-3

2 GR1 Espressos 014 h 4 CN7-4

2 GR1 Medium 015 h 5 CN7-5

2 GR1 Large 016 h 6 CN7-6

1 GR2 Espresso 021 h 7 CN7-7

1 GR2 Medium 022 h 8 CN7-8

1 GR2 Large 023 h 9 CN7-9

2 GR2 Espressos 024 h 10 CN7-10

2 GR2 Medium 025 h 11 CN7-11

2 GR2 Large 026 h 12 CN7-12

1 GR3 Espresso 031 h 13 CN7-13

1 GR3 Medium 032 h 14 CN7-14

1 GR3 Large 033 h 15 CN7-15

2 GR3 Espressos 034 h 16 CN7-16

2 GR3 Medium 035 h 17 CN7-17

2 GR3 Large 036 h 18 CN7-18

1 GR4 Espresso / Cappuccino 041 h 19 CN7-19

1 GR4 Medium / Latte 042 h 20 CN7-20

1 GR4 Large / Frothed milk 043 h 21 CN7-21

2 GR4 Espressos / Warm milk 044 h 22 CN7-22

2 GR4 Medium / Latte Macchiato 045 h 23 CN7-23

2 GR4 Large 046 h 24 CN7-24

Tea 1 051 h 25 CN7-25

Tea 2 052 h 26 CN7-26

CN7-33 I/O enabling

CN7-35 I/O enabling

CN7-37 com. relay

CN7-38 com. relay
