13
STORING THE WEIGHT BENCH
You can store either the Curl Post (9) or the Lat
Tower (14) on the storage tube on the right base
when they are not in use.
Before storing the weight bench, remove any
weights from the Leg Lever (8), slide the Lat
Tower (14) onto the storage tube, and adjust the
Backrest (18) to the highest inclined position. To
store the weight bench, first remove the Frame Knob
(37) and the Crossbar Pin (29) from the indicated
bracket. Next, lift the Front Leg (2) as far as it will go.
Next, insert the Frame Knob into the bracket. Then,
insert the Crossbar Pin into the bracket. The Crossbar
Pin will prevent the weight bench from unfolding.
Note: For clarity, the left fly arm is not shown.
Bracket
Storage
Tube
2
14
9
37
29
8
18
ATTACHING THE LAT BAR
T
o attach the Lat Bar (23) to the Cable (21), attach
a Weight Clip (48) to the Cable and the Lat Bar.
2
1
23
48
