REMOVE THIS PART IDENTIFICATION CHART AND PART LIST/
EXPLODED DRAWING. SAVE THIS PART IDENTIFICATION CHART
AND PART LIST/EXPLODED DRAWING FOR FUTURE REFERENCE.
PART LIST—Model No. 831.159300 R0903A
125/16” x 2 1/2” Carriage Bolt
231/4” Nylon Locknut
3125/16” Nylon Locknut
41Base
51Stabilizer
63“V”-pulley
733/8” x 2 1/2” Bolt
845/16” Washer
943/8” Washer
10 6 1/4” Washer
11 45/16” x 2 3/4” Bolt
12 4 3/8” x 2” Bolt
13 1 Seat
14 3 5/16” x 2 3/4” Carriage Bolt
15 8 3 1/2” Pulley
16 1 3/8” x 3 1/2” Bolt
17 1 Press Frame
18 2 1/4” x 3/4” Screw
19 2 Weight Bumper
20 1 Pulley Bracket
21 17 3/8” Nylon Locknut
22 4 3/8” x 2 3/4” Bolt
23 1 Long Cable
24 1 1/4” x 2” Screw
25 6 Weight
26 1 Weight Pin
27 2 2” Square Inner Cap
28 2 Pad Tube
29 1 Leg Lever
30 4 5 1/2” Pad
31 2 Handgrip
32 1 1 1/2” Square Inner Cap
33 4 2” Round Inner Cap
34 4 3/4” Round Inner Cap
35 1 3/8” x 2” Eyebolt
36 1 Seat Frame
37 1 Seat Plate
38 1 1/4” x 2” Carriage Bolt
39 1 Handle
40 1 Seat Knob
41 1 Backrest
42 1 Front Upright
43 2 1/4” x 2 1/2” Screw
44 2 1 3/4” Square Inner Cap
45 2 10” Pad
46 1 Right Press Arm
47 1 Left Arm
48 1 Right Arm
49 4 1” Round Inner Cap
50 3 Long Cable Trap
51 2 Stabilizer Foot
52 1 Chain
53 3 Cable Clip
54 1 Lat Bar
55 1 Top Frame
56 4 #8 x 3/4” Screw
57 1 Long “U”-bracket
58 1 Short Cable
59 1 3/8” x 8” Bolt
60 1 5/16” x 6” Bolt
61 2 1/2” x 17/32” Spacer
62 2 Weight Guide
63 1 Weight Tube
64 1 Weight Tube Bumper
65 1 1” Square Inner Cap
66 5 Cable Trap
67 1 Small “U”-bracket
68 1 5/16” x 5” Bolt
69 4 1” Retainer
70 2 1” Round Cover Cap
71 3 3/8” x 3 3/4” Bolt
72 1 5/16” x 1 3/4” Bolt
73 1 Left Press Arm
74 2 1 1/8” x 2 1/2” Plastic Bushing
75 2 1” x 7/8” Plastic Bushing
76 1 Top Weight
77 1 1 1/2” Round Inner Cap
78 2 Round Inner Cap
79 2 2” x 3” Inner Cap
80 1 5/16” x 2 1/2” Bolt
#1User’s Manual
#1Exercise Guide
Key No. Qty. Description Key No. Qty. Description
