WeiderPro 225 - Part Identification Chart

This chart is provided to help you identify the small parts used in assembly. The number in parenthesis below
e
ach part refers to the key number of the part, from the PART LIST in the center of this manual. I
mportant:
Some parts may have been pre-assembled for shipping purposes. If you cannot find a part in the parts
b
ags, check to see if it has been pre-assembled.
M10 x 80mm Bolt (35)
M8 Nylon Locknut (22)
M8 Washer (23)
M10 Nylon Locknut (19)
M6 Washer (25)
M10 Washer (24)
M10 x 75mm Bolt (10)
M10 x 175mm Bolt (17)
M4 x 8mm Screw (34)
M10 x 70mm Bolt (18)
M6 x 38mm Screw (16)
M6 x 16mm Screw (15)
M10 x 52mm Carriage Bolt (9)
