3. Click left and right arrow buttons to move the camera. Stop moving the camera
until the cross in camera center is at the hole center.
4. Click Record Pos 2. The system will automatically calculate the offsets in both
X-axis and Y-axis.
Picking Template
In shoot-cut mode, marks (also called marking point or template) are used to figure
out the tool path.
Requirements of the target marking points:
• Clear enough
• Being unique
Steps
1. Turn to Manual mode, and click Vision → CCD to switch to CCD interface.
2. Click Mark 1, Mark 2 and Mark 3 in order. Three marking points will be
recorded.
Tip: For how many marking points you need to take, see Should I use
two templates or three templates?
Tip: It is recommended to take marking points at specified shooting
positions on workpiece that will be machined next.
3. Click Show Box, and select templates of different size by dragging the mouse.
Make sure characteristic of the template is obvious enough.
