3.4.1.1.6 Fuji FALDIC-β
The parameters and descriptions are shown below:
Command pulse numerator α, 02 Command pulse denominator β
o Description: Stand for electronic gear ratio numerator and denominator.
o Unit: -
o Range: 1–32767
o Equation: α/β = (encoder resolution × pulse equivalent × mechanical
reduction ratio)/screw pitch
o Value: When encoder resolution = 65536, pulse equivalent = 0.001, screw
pitch = 5 mm, and mechanical reduction ratio = 1:
α/β=65536×0.001/5=8192/625, which means α=8192 and β=625.
Pulse train input format
o Description: Pulse train input format
o Unit: -
o Range: 0: The pulse train input format is pulse + direction (symbol), negative
logic
o Value: 0
Rotation direction
o Description: Rotation direction
o Unit: -
o Range
0: Rotates CW (anti-clockwise when observing from the load side)
1: Rotates CCW (clockwise when observing from the load side)
o Value: 0 or 1
CONT1 signal distribution
o Description: CONT1 signal distribution
o Unit: -
o Range: 1: CONT1 is distributed to RUN (SON). If CONT1 is not distributed, it
becomes ON if there is no alarm after power-on.
o Value: 1
CONT2 signal distribution
o Description: CONT2 signal distribution
o Unit: -
o Range: 2: CONT2 is distributed to RST (CLR: servo alarm clearing).
Parameter 12, 13, and 14 are 0, which means that CONT3, CONT4, and
CONT5 cannot be distributed to OT (overtravel) or EMG (external
emergency stop).
o Value: 2
OUT1 signal distribution
o Description: OUT1 signal distribution
o Unit: -
o Range
1: OUT1 is distributed to alarm output contact a, which is normally
open.
2: OUT1 is distributed to alarm output contact b, which is normally
closed.
o Value: 1
Parameter modification inhibition
o Description: Parameter modification inhibition
