3 Technical data
Back to contents >
3 Technical data
3.1 Technical data charts
Dimensions and weights
Width
Including packaging
535
[mm]
21.1
[in]
Appliance without packaging
356
[mm]
14.0
[in]
Height
Including packaging
850
[mm]
33.5
[in]
Appliance ("Classic" exterior) without packaging
620
[mm]
24.4
[in]
Appliance ("Trend" exterior) without packaging
644
[mm]
25.4
[in]
Depth
Including packaging
895
[mm]
35.3
[in]
Appliance without packaging, door closed
636
[mm]
25.0
[in]
Weight
High power version, including packaging
70.4
[kg]
155
[lbs]
High power version, excluding packaging
61.0
[kg]
134
[lbs]
Standard power version, including packaging
61.1
[kg]
135
[lbs]
Standard power version, excluding packaging
51.7
[kg]
114
[lbs]
Safety clearances
Right / Left
0
[mm]
0
[in]
Top / Rear (for ventilation)
50
[mm]
2
[in]
Electrical connected load ratings - High power version
Electrical supply
1N~ 220-230V 50Hz
2N~ 380-400V 50Hz
1N~ 220V 60Hz
2~ 200V 50/60Hz
Connections used
L + N + E
L1 + L2 + N + E
L + N + E
2P + E
Arrangement
Single phase
Twin phase
Single phase
Two pole
Rated power consumption
[W]
6000
2500 + 3300
6000
6000
Rated current per phase
[A]
32
16 / 32
32
32
Power output
Rated power output convected
heat
[W]
2200
2200
2200
2000
Rated power output microwave
(IEC 705) 100%
[W]
2000
2000
2000
2000
Rated power output
combination mode
[W]
2200 + 2000
2200 + 2000
2200 + 2000
2000 + 2000
Electrical connected load ratings - Standard power version
Electrical supply
1N~ 220-230V 50Hz
1N~ 220-230V
50Hz
1N~ 220V 60Hz
2~ 208V 60Hz
Connections used
L + N + E
L + N + E
L + N + E
2P + E
Arrangement
Single phase
Single phase
Single phase
Two pole
Rated power consumption
[W]
2990
3680
2860
4160
Rated current per phase
[A]
13
16
13
20
Power output
Rated power output convected
heat
[W]
2200
2200
2200
2200
Rated power output
microwave (IEC 705) 100%
[W]
1000
1000
1000
1000
Rated power output
combination mode (convected
heat + microwave)
[W]
900 + 1000
1300 + 1000
900 + 1000
2200 + 1000
