Merrychef eikon
®
e2s service and repair manual
32
_______________________________________________________________________________________________________________________________
_______________________________________________________________________________________________________________________________
3 Technical data
Back to contents >
Description
Features
Function
Rating
Trouble shooting
Green (or Red on some
models) is negative,
and White (or Yellow
on some models) is
positive.
temperature to verify
proper reading.
Check for opens, shorts
or grounds.
K Type Junction at 25
o
C ambient (1VDC = 1,000mVDC)
o
C
mVDC
(°F)
o
C
mVDC
(°F)
0°C
0
(32°F)
125°C
5.1
(257°F)
25°C
1
(77°F)
150°C
6.1
(302°F)
50°C
2
(122°F)
200°C
8.1
(392°F)
75°C
3.1
(167°F)
250°C
10.2
(482°F)
100°C
4.1
(212°F)
300°C
12.2
(572°F)
*Note 1: 12A fuse (F3) used in Americas
*Note 2: 208/240 HV Transformers used in most 60Hz applications
*Note 3: 0.95 µ F Capacitors used in most 60Hz applications. 1.0 µ F Capacitors used in specialised applications
Always review country specific service parts lists for required replacements. Never use non-approved alternatives.
See section 6.19 for the Technical Data Summary Sheet
3.2 Dimensional drawings
eikon
®
e2s
Front view (door closed) Cavity dimensions (door closed)
View from the top (door closed) View from the right hand side (door open)
