4. To remove the printout, pull the paper forward and to the left or right to
tear it along the cutting edge.
5. To obtain an additional copy of the test results, leave the Handle in the
well and press the PRINT
button again. Removing the MicroTymp2
Handle from the well causes the data to be removed from the Printer/
Charger memory.
NOTE:
• The Printer/Charger has been pre-set at Welch Allyn to print
a complete printout as illustrated in Figure 21 on page 17,
and to print in manual mode. To change formats or print in
automatic mode, follow the instructions on page 20.
• If only one ear has been tested, the memory for the other
ear should be erased (see page 8) so as not to confound
current data with data from a previous patient.
• If only one memory location has data, only one result is printed.
• Do not use transparent adhesive tape on the printed portions
of a printout, as those portions will then fade.
MicroTymp2 Printout Formats
Description of Formats
A complete tympanometric printout is shown in Figure 21. The printout is
divided into three sections: tympanogram, data, and interpretive messages.
Following is a detailed account of the information presented in each of these
sections. For instructions on changing the format of the printout, see page 20.
16
