MicroTymp2 Printer/Charger Components
Figure 1B
Preparing to Use the MicroTymp2 Handle
and Printer/Charger
The following is a list of important facts to note before using the
MicroTymp2.
• Please complete and return the warranty registration card. It validates
the warranty, and allows Welch Allyn to communicate recalibration
notices and software changes.
3
To Power
Receptacle
To IEC Power
Cord Receptacle
Power Cord
134
OFF
2
POWER CHARGE FEED PRINT
Charging
Well for
MicroTymp2
Paper Access
Cover
Paper
Slot
Tip Box
POWER
Indicator
CHARGE
Indicator
FEED Button
PRINT Button
IEC Power
Cord Receptacle
Printer/Charger
Switches
TM
To Next Page
