Paper Replacement
The MicroTymp2 Printer/Charger signals the need for changing the paper in
one of two ways:
• A pink strip appears along the edge of the paper indicating the paper is
nearing the end of the roll.
• The POWER
indicator flashes in single pulses indicating that there is
no paper, and no printing can occur.
NOTE:
• Use only an appropriate heat-sensitive paper or the Printer/
Charger life may be shortened and the warranty voided.
• The paper is thermally activated, so it must be stored in a
cool, dark location to prevent exposure and degraded
performance.
• Because the paper is thermally activated, no printing will
appear on the paper if it is inserted backwards.
• Do not use transparent adhesive tape on printed portions
of the printout, as those portions will then fade.
To Replace the Paper
CAUTION: Disassembly of the Printer/Charger presents a
possible electrical-shock hazard. Refer all servicing to Welch
Allyn or a Welch Allyn authorized service representative, listed
on page E-55.
1. Remove the paper access cover by pulling up on the front edge. See
Figure 40.
Figure 40
C-48
Appendix C
