Weldclass Weldforce 202T - Accessories, Spare Parts & Circuit Diagrams; TIG Torch and Spares

.
26 © Weldclass 2020 | E.&O.E.
8 ACCESSORIES, SPARE PARTS & CIRCUIT
DIAGRAMS
8.1 TIG Torch and Spares:
To view TIG torch and parts, go to: www.weldclass.com.au
Part No.
Description
P3-TB26
Torch Body - 17 Standard (No Valve)
P3-TB26F
Torch Body - 17F Flexible (No Valve)
WC-57Y02P
Back cap – Long Pk2
WC-57Y05P
Back cap – Medium Pk2
WC-57Y04P
Back cap – Short Pk2
P3-10N23
Collet – 1.6mm
P3-10N24
Collet – 2.4mm
P3-10N25
Collet – 3.2mm
P3-10N31
Collect Body – 1.6mm Pk2
P3-10N32
Collect Body – 2.4mm Pk2
P3-10N28
Collect Body – 3.2mm Pk2
P3-10N49
TIG Ceramic Cup - #5 7.9mm Pk2
P3-10N48
TIG Ceramic Cup - #6 9.5mm Pk2
P3-10N47
TIG Ceramic Cup - #7 11.1mm Pk2
P3-10N46
TIG Ceramic Cup - #8 12.7mm Pk2
P3-10N45
TIG Ceramic Cup - #10 15.8mm Pk2
WC-05192
TIG Tungsten RE4 – 1.6mm Pk10
WC-05193
TIG Tungsten RE4 – 2.4mm Pk10
WC-05194
TIG Tungsten RE4 – 3.2mm Pk10
Table 4
Figure 14
