3 KNOW YOUR MACHINE
3.1 Machine Rear
1. Mains Power Switch
2. 240V AC Mains Power Input Lead
3. Gas Inlet Connection
4. Fuse
5. Water Cooler Interface
6. Remote Control Interface
3.2 Machine Front
1. Positive Dinse Socket
2. Negative Dinse Socket
3. TIG torch Interface Connector
4. TIG Torch Gas Connector
Figure 2
Figure 1
