2 SPECIFICATIONS
Description
WeldForce 202T AC/DC
Part Number
WC-202T
Dimensions
L430 x W170 x H340mm (including handle)
Weight of Power Source
16.35kg
Standard
AS 60974.1
Power Supply
240V +/- 15% 50hz Single Phase
Factory Fitted Plug Rating
10A
Open Circuit Voltage U
0
VRD On = 15V / VRD Off = 95A
TIG Tungsten Size
1.6 – 2.4mm
MMA Electrode Size
1.6 – 4.0mm
Protection Class
IP23
TIG (GTAW) Welding
15A Power Supply**
10A Power Supply*
Welding Current Output
5 – 200A
5 – 180A
Duty Cycle
200A / 18.0V @ 24%
115A / 14.6V @ 60%
100A / 14.0V @ 100%
180A / 17.2V @ 19%*
115A / 14.6V @ 60%
100A / 14.0V @ 100%
Effective Input Current
14A
10A*
Maximum Input Current
33A
30A
DC Stick (MMA) Welding
20A Power Supply***
15A Power Supply**
10A Power Supply*
Welding Current Output
5 – 160A
5 – 160A
5 – 150A
Duty Cycle
160A / 26.4V @ 30%
110A / 24.4V @ 60%
95A / 23.8V @ 100%
160A / 26.4V @ 20%**
100A / 24.4V @ 60%**
80A / 23.2V @ 100%**
150A / 26.0V @ 12%*
75A / 23.0V @ 60%*
60A / 22.4V @ 100%*
*Effective Input Current
I
1eff
18A
I
1eff
15A
I
1eff
10A
Maximum Input Current
I
1max
33A
I
1max
33A
I
1max
30A
Table 1
*This machine is factory fitted with 10A plug for commissioning purposes only. Whilst 10A plug is fitted,
the operator must set to 10A (CL.2) mode and ensure that output and duty cycle limits indicated above are
not exceeded.
**If using on 15A power supply, 15A plug should be installed by a qualified person (such as a licensed
electrician) – and if using in MMA (stick) welding mode, the operator must ensure that output and duty
cycle limits indicated above are not exceeded.
***If using on 20A power supply (to allow full output in MMA mode), 20A plug should be installed by a
qualified person (such as a licensed electrician).
For full machine specifications, refer to technical data plate on base of machine.
