WEMPE 20097 - System Overview

WEMPE digital main clock 20097
Design and function
V3.0 01/2011 13
1.1.2 System overview
24V D
C
12
39
6
24V DC 230V AC
12
30
00
3
4
5
67
2
1
Ill. 2: System overview
1 GPS or DCF77 connection
2 digital main clock 20097
3 analogue secondary clocks
4 analogue secondary clocks with seconds display
5 digital secondary clocks (optional)
6 external interface
7 external mains adaptor
