WEMPE 20097 - Protocol MITEL

WEMPE digital main clock 20097
Annex
V3.0 01/2011 55
1.1.8 Protocol MITEL
Data scope: 1 Start bit
7 Data bit
1 Parity bit (even)
2 Stop bit
4.800 Baud
transmission only if time is set up anew
Byte Mark Description
1 ESC HEX1B
2 1
3 M
4 A
5 I
6 N
7 T
8 1
9 CR HEX0D Carriage return
10 S
11 X
12 2
13 0
14 0
15 0
16 CR HEX0D Carriage return
17 ESC HEX1B
18 6
19 T
20 I
21 M
22 E
23 SPACE HEX20
24 10h Hour ten LT
25 1h Hour one LT
26 : HEX3A
27 10m Minute ten LT
28 1m Minute one LT
29 CR HEX0D Carriage return
30 D HEX44
31 E HEX45
32 S HEX53
33 K HEX4B
34 CR HEX0D Carriage return
35 ESC HEX1B
36 1 HEX1B
