WEMPE digital main clock 20097
Annex
V3.0 01/2011 37
9 Annex
1.1 Terminal plans
1.1.1 Terminal plan for the standard version
Terminal
1
--- Akkumulator / accumulator + 12V
Interne Stromversorgung
2
--- Akkumulator / accumulator 0V
internal power supply
25
--- GND
3
--- GND
Alternativ / alternative
7
--- Analogline / analogue line 2 Sekundenimpulse Minute rückwärts
8
--- Analogline / analogue line 2 second impulse minute backwards
Alternativ / alternative
32
--- Analogline / analogue line 1 Minutenimpulse Minute vorwärts
33
--- Analogline / analogue line 1 minute impulse minute forwards
26
--- GND
27
--- GND
13
--- RS485/422 TxD+
37
--- RS485/422 TxD-
14
--- PPS+ Output
38
--- PPS- Output
39
--- GND
15
--- GPS-PPS-Pulse
40
--- GPS-PPS-GND
16
--- GPS-Data
41
--- GPS-Data-GND
21
--- Relay 1 common com
45
--- Relay 1 normal open no
46
--- Relay 1 normal close no
22
--- Relay 2 normal open no
23
--- Relay 2 normal close no
47
--- Relay 2 common com
24
--- power supply + 24V DC Stromversorgung + 24V DC
48
--- power supply 0V Stromversorgung 0V
