WEMPE 20097 - Protocol ITRON 2000 Interface RS422;485

WEMPE digital main clock 20097
Annex
50
V3.0 01/2011
1.1.3 Protocol ITRON 2000 Interface RS422/485
Data scope: 1 Start bit
7 Data bit
1 Parity bit (even)
2 Stop bit
4.800 Baud
transmission once a second
Byte Mark Description
1 STX HEX02 Start of text
2 U HEX55 Data transmission of the UTC-time
3 10h Hour ten
4 1h Hour one
5 10m Minute ten
6 1m Minute one
7 10s Second ten
8 1s Second one
9 D HEX44 Data transmission of the UTC-date
10 10d Day ten
11 1d Day one
12 10m Month ten
13 1m Month one
14 1000y Year thousand
15 100y Year hundred
16 10y Year ten
17 1y Year one
18 L HEX4C Data transmission of the LT-time
19 10h Hour ten
20 1h Hour one
21 10m Minute ten
22 1m Minute one
23 10s Second ten
24 1s Second one
25 D HEX44 Data transmission of the LT-date
26 10d Day ten
27 1d Day one
28 10m Month ten
29 1m Month one
30 1000y Year thousand
31 100y Year hundred
32 10y Year ten
33 1y Year one
34 LF HEX0A Line feed
35 CR HEX0D Carriage return
36 ETX HEX03 End of text
