WEMPE 20097 - Protocol ECHO

WEMPE digital main clock 20097
Annex
52
V3.0 01/2011
1.1.5 Protocol ECHO
Data scope: 1 Start bit
7 Data bit
1 Parity bit (even)
2 Stop bit
4.800 Baud
transmission once a second
Byte Mark Description
1 LF HEX0A Line feed
2 LF HEX0A Line feed
3 NUL
4 NUL
5 NUL
6 NUL
7 NUL
8 NUL
9 NUL
10 NUL
11 NUL
12 NUL
13 G HEX47 Data transmission of the UTC-time
14 10h Hour ten
15 1h Hour one
16 10m Minute ten
17 1m Minute one
18 10s Second ten
19 1s Second one
20 L HEX4C Data transmission of the LT-time
21 10h Hour ten
22 1h Hour one
23 10m Minute ten
24 1m Minute one
25 10s Second ten
26 1s Second one
27 D HEX44 Data transmission of the UTC-date
28 10d Day ten
29 1d Day one
30 10m Month ten
31 1m Month one
32 10y Year ten
33 1y Year one
34 CR HEX0D Carriage return
