Wen 3959 User Manual

No. Part No. Description Qty.
1 3959-001 Lower Door 1
2 3959-002 Hex Screw M6X10 2
3 3959-003 Spring Washer Φ6 3
4 3959-004 Nut M6 5
5 3959-005 Screw M4X10 4
6 3959-006 Window 1
7 3959-007 Upper Door 1
8 3959-008 Saw Blade 1
9 3959-009 Shaft Circlip 2
10 3959-010 Bearing 4
11 3959-011 Hole Circlip Φ26 4
12 3959-012 Screw M4X8 2
13 3959-013 Rubber Gasket 2
14 3959-014 Driven Pulley 1
15 3959-015 M8X70 Bolt 1
16 3959-016 Brush 1
17 3959-017 Scale Label 1
18 3959-018 Upper Wheel Shaft 1
19 3959-019 Upper Wheel Shaft Base 1
20 3959-020 Split Washer M6 2
21 3959-021 Connection Shaft 1
22 3959-022 Blade Wheel 2
23 3959-023 U Type Support 1
24 3959-024 Bolt 1
25 3959-025 Hex Nut M4 2
26 3959-026 Switch 1
27 3959-027 Switch Plate 1
28 3959-028 Locking Washer 1
29 3959-029 Guide Base 1
30 3959-030 Screw 7
31 3959-031 Guide Cover 1
32 3959-032 Cover Spring 1
33 3959-033 Screw 1
34 3959-034 Slide Board 1
No. Part No. Description Qty.
35 3959-035 Upper Guide Slide Bar 1
36 3959-036 Hex Screw M4X4 1
37 3959-037 Pin 5X14 4
38 3959-038 Upper Blade Guide Support 1
39 3959-039 Upper Support Shaft 1
40 3959-040 Flat Washer M5 3
41 3959-041 Ball Bearing 2
42 3959-042 Bearing Fastening Screw 2
43 3959-043 Hex Screw M5X10 3
44 3959-044 Hex Screw M5X12 4
45 3959-045
Philips Screw+Flat
Washer+Spring Washer As
-
sembly M4X8
6
46 3959-046 Belt 1
47 3959-047 Hex Nut M12X1.5 1
48 3959-048 Spring Washer M12 1
49 3959-049 Lower Wheel Shaft 1
50 3959-050 Hex Screw M5X10 1
51 3959-051 Big Flat Washer 1
52 3959-052 Driven Pulley 1
53 3959-053 Guide Plate 1
54 3959-054 Hex Nut M10 1
55 3959-055 Hex Screw M6X8 2
56 3959-056 Blade Lower Guard 1
57 3959-057 Saw Body 1
58 3959-058 Block 1
59 3959-059 Tension Spring 1
60 3959-060 Tension Handle 1
61 3959-061 Flat Washer D8 2
62 3959-062 Hex Nut M8 1
63 3959-063 Wing Locking Nut 1
64 3959-064 Blade Wheel Adjusting Knob 1
65 3959-065 6P4 Clip 2
EXPLODED VIEW & PARTS LIST
NOTE: Not all parts may be available for purchase. Parts and accessories that wear down over the course of
normal use are not covered under the warranty.

Wen 3959 Specifications

General

Brand	Wen
Model	3959
Category	Saw
Language	English
