No. Part No. Description Qty.
66 3959-066 Power Cord 1
67 3959-067 Hex Screw M8X25 2
68 3959-068 Flat Washer M8 1
69 3959-069 Motor 1
70 3959-070 Locking Knob 1
71 3959-071 Eccentric Locking Knob 2
72 3959-072 Flat Washer D6 2
73 3959-073 Hex Screw M6X25 2
74 3959-074 Adjusting Gear 1
75 3959-075 Adjusting Handle Base 1
76 3959-076 Adjusting Handle 1
77 3959-077 Dust Port 1
78 3959-078 Hex Bolt M6X20 4
79 3959-079 Hex Nut M6 5
80 3959-080 Shaft 1
81 3959-081 Locking Spring 2
82 3959-082 Gear Handle 1
83 3959-083 Table Pointer 1
84 3959-084 Hex Bolt M6X25 1
85 3959-085 Table Insert 1
86 3959-086 Work Table 1
87 3959-087 Table Locking Knob 2
88 3959-088 Fence Locking Knob 1
89 3959-089 Angle Support 1
90 3959-090 Hex Bolt M6X12 4
91 3959-091 Pin 3X16 1
92 3959-092 Butterfly Nut M6 1
93 3959-093 Flat Washer D6 4
94 3959-094 Slide Bar 1
95 3959-095 Miter Gauge Knob 1
96 3959-096 Miter Gauge 1
97 3959-097
Philips Screw+Flat
Washer+Spring Washer As
-
sembly M5X8
1
No. Part No. Description Qty.
98 3959-098 Miter Gauge Pointer 1
99 3959-099 Lower Support Shaft 1
100 3959-100 Lower Blade Guide Support 1
101 3959-101 Spring Washer D10 1
102 3959-102 Capacitor 1
103 3959-103
Philips Screw+Flat Washer
M4X6
2
104 3959-104 Capacitor Box 1
105 3959-105
Wavy Washer ɸ6
1
106 3959-106
Lower Blade Guide Support
Base
1
107 3959-107 Hex Bolt M6X40 1
108 3959-108 Wrench S=10 1
109 3959-109 Hex Wrench S=4 1
110 3959-110 Hex Wrench S=2 1
111 3959-111 Screw M4X8 4
112 3959-112 Spring Washer D8 1
113 3959-113 Screw M5X16 3
114 3959-114 Flat Washer D6 3
115 3959-115 Fence Locking Plate 1
116 3959-116 Fence Locking Spring 1
117 3959-117 Fence Washer 2
118 3959-118 Hex Bolt M6X16 2
119 3959-119 Fence Plate 1
120 3959-120 Fence Work Rest 1
121 3959-121 Bolt 1
EXPLODED VIEW & PARTS LIST
NOTE: Not all parts may be available for purchase. Parts and accessories that wear down over the course of
normal use are not covered under the warranty.
To Next Page
