Wen 3966 User Manual

20
No. Part Number Description
Qty.
118 3966-118 Limiting shaft 1
119 3966-119 Hex nut 1
120 3966-120 Guide block 1
121 3966-121 Lower guard 1
122 3966-122 Hex head bolt 1
123 3966-123 Flat washer 2
124 3966-124 Shaft 1
125 3966-125 Hex nut 4
126 3966-126 Hex head bolt 4
127 3966-127 Hex nut 1
128 3966-128 Hex head bolt 1
129 3966-129 Hex head bolt 1
130 3966-130 Flat washer 2
131 3966-131 Guide block 1
132 3966-132 Set screw 1
133 3966-133 Socket head screw 1
134 3966-134 Socket head screw 1
135 3966-135 Pin 1
136 3966-136 Dust port cover 1
137 3966-137 Dust port 1
138 3966-138 Pan head screw 3
139 3966-139 Set screw 1
140 3966-140 Bushing 1
141 3966-141 Idle pulley shaft 1
142 3966-142 Idle pulley 1
143 3966-143 Ball bearing 2
144 3966-144 Retaining ring 1
145 3966-145 Belt 1
146 3966-146 Motor pulley 1
147 3966-147 Set screw 1
148 3966-148 Key 1
149 3966-149 Motor 1
150 3966-150 Flat washer 4
151 3966-151 Socket head screw 4
152 3966-152 Belt tension knob 1
153 3966-153 Retaining ring 1
154 3966-154 Gear 2
155 3966-155 Table adjusting knob 1
156 3966-156 Lock knob 4
157 3966-157 Table 1
158 3966-158 Table insert 1
159 3966-159 Carriage blot 1
160 3966-160 Angle guide plate 2
161 3966-161 Table bevelling base 1
162 3966-162 Socket head bolt 2
163 3966-163 Flat washer 2
164 3966-164 Lock nut 2
165 3966-165 Pan head screw 1
166 3966-166 Flat washer 1
167 3966-167 Pointer 1
168 3966-168 Flat washer 4
169 3966-169 Hex head bolt 4
170 3966-170 Flat washer 4
171 3966-171 Socket head screw 4
172 3966-172 Hex nut 4
173 3966-173 Limiting plate 1
174 3966-174 Hex head bolt 1
175 3966-175 Locking handle 1
176 3966-176 Cap 1
EXPLODED VIEW & PARTS LIST
No. Part Number Description
Qty.
177 3966-177 Handle 1
178 3966-178 Washer 1
179 3966-179 Miter gauge 1
180 3966-180 Pan head screw 1
181 3966-181 Pointer 1
182 3966-182 Rod 1
183 3966-183 Socket head screw 1
184 3966-184 Cord clamp 1
185 3966-185 Flat washer 1
186 3966-186 Nut 1
187 3966-187 Hex nut 2
188 3966-188 LED driver 1
189 3966-189 Power cord 1
190 3966-190 Inner cord 2
191 3966-191 Knob 2
192 3966-192 Flat washer 2
193 3966-193 Fence support cap 2
194 3966-194 Fence support 1
195 3966-195 Guide plate 1
196 3966-196 Carriage blot 2
197 3966-197 Fence 1
198 3966-198 Socket head bolt 2
199 3966-199 Spacer plate 1
200 3966-200 Nut 3
201 3966-201 Sliding base 1
202 3966-202 Pointer 1
203 3966-203 Thread forming screw 2
204 3966-204 Spring plate 1
205 3966-205 Pan head screw 1
206 3966-206 Lock block 1
207 3966-207 Lock handle 1
208 3966-208 Shaft 1
209 3966-209 Guide rail cap 1
210 3966-210 Guide rail 1
211 3966-211 Guide rail cap 1
212 3966-212 Flat washer 8
213 3966-213 Socket head screw 8
214 3966-214 Long brace 2
215 3966-215 Leg 4
216 3966-216 Hex nut 8
217 3966-217 Flat washer 8
218 3966-218 Carriage blot 8
219 3966-219 Short brace 2
220 3966-220 Push stick 1
221 3966-221 Hook 1
222 3966-222 Hex nut 1
223 3966-223 Rack 1
224 3966-224 Pan head screw 2
225 3966-225 Spanner 1
226 3966-226 6mm hex wrench 1
227 3966-227 5mm hex wrench 1
228 3966-228 4mm hex wrench 1
229 3966-229 3mm hex wrench 1
230 3966-230 Sliding bar 1
231 3966-231 Locking knob 1
232 3966-232 Center Pin 1
233 3966-233 Support block 1
234 3966-234 Socket head screw 1
235 3966-235 Locking knob 1
