EXPLODED VIEW AND PARTS LIST
No. Part Number Description Qty
1 3970-001 Worm gear pulley 1
2 3970-002 Set screw 1
3 3970-003 Pan head screw 1
4 3970-004 Flat washer 1
5 3970-005 Flat head screw 2
6 3970-006 Bearing cover 1
7 3970-007 Oil seal 1
8 3970-008 Ball bearing 1
9 3970-009 Bearing bushing 1
10 3970-010 Ball bearing 1
11 3970-011 Worm gear 1
12 3970-012 V belt 1
13 3970-013 Hex head bolt 6
14 3970-014 Lock washer 6
15 3970-015 Flat washer 6
16 3970-016 Gear box cover 1
17 3970-017 Gear box gasket 1
18 3970-018 Key 2
19 3970-019 Worm assembly 1
20 3970-020 Spring pin 1
21 3970-021 Worm gear 1
22 3970-022 Hex head bolt 1
23 3970-023 Hex head bolt 1
24 3970-024 Hex head bolt 1
25 3970-025 Flat washer 1
26 3970-026 Hex head bolt 4
27 3970-027 Lock washer 4
28 3970-028 Sliding block 1
29 3970-029 Flat washer 4
30 3970-030 Guide plate 2
31 3970-031 Shaft block 1
32 3970-032 Shaft 1
33 3970-033 Blade tension nut 1
34 3970-034 Spring 1
35 3970-035 Flat washer 1
36 3970-036 Blade tension knob 1
37 3970-037 Bushing 1
38 3970-038 Ball bearing 2
39 3970-039 Retaining ring 2
40 3970-040 Rear blade wheel 1
41 3970-041 Flat washer 1
42 3970-042 Flat washer 1
43 3970-043 Socket head screw 1
44 3970-044 Blade 1
45 3970-045 Switch cut off finger 1
46 3970-046 Flat washer 1
47 3970-047 Lock washer 1
48 3970-048 Pan head screw 1
49 3970-049 Rear guide tighten knob 1
50 3970-050 Flat washer 1
51 3970-051 Bushing 1
52 3970-052 Ball bearing 2
53 3970-053 Oil seal 1
54 3970-054 Bearing cover 1
55 3970-055 Flat head screw 3
No. Part Number Description Qty
56 3970-056 Bushing 1
57 3970-057 Front blade wheel 1
58 3970-058 Set screw 1
59 3970-059 Retaining ring 1
60 3970-060 Flat washer 4
61 3970-061 Pan head screw 4
62 3970-062 Frame 1
63 3970-063 Hex head bolt 1
64 3970-064 Hex nut 1
65 3970-065 Hex head bolt 1
66 3970-066 Flat washer 1
67 3970-067 Pan head screw 1
68 3970-068 Lock washer 1
69 3970-069 Flat washer 1
70 3970-070 Hex head bolt 1
71 3970-071 Motor support plate 1
72 3970-072 Hex head bolt 1
73 3970-073 Hex nut 1
74 3970-074 Hex nut 4
75 3970-075 Lock washer 4
76 3970-076 Flat washer 4
77 3970-077 Hex head bolt 4
78 3970-078 Hex head bolt 1
79 3970-079 Belt cover 1
80 3970-080 Knob 1
81 3970-081 Flat washer 1
82 3970-082 Pan head screw 1
83 3970-083 Set screw 1
84 3970-084 Motor pulley 1
85 3970-085 Key 1
86 3970-086 Motor 1
N/A 3970-086-01 Motor Fan Cover 1
N/A 3970-086-02 Motor Capacitor 1
N/A 3970-086-03 Motor Capacitor Cover 1
87 3970-087 Front guide base 1
88 3970-088 Flat washer 1
89 3970-089 Lock washer 1
90 3970-090 Hex head bolt 1
91 3970-091 Hex nut 2
92 3970-092 Lock washer 2
93 3970-093 Ball bearing 1
94 3970-094 Shaft 1
95 3970-095 Front blade guide 1
96 3970-096 Shaft 2
97 3970-097 Ball bearing 2
98 3970-098 Retaining ring 2
99 3970-099 Front blade guard 1
100 3970-100 Flat head screw 2
101 3970-101 Hex nut 2
102 3970-102 Lock washer 2
103 3970-103 Hex head bolt 1
104 3970-104 Lock washer 1
105 3970-105 Flat washer 1
106 3970-106 Ball bearing 1
107 3970-107 Shaft 1
