Wen BA1411 User Manual

EXPLODED VIEW & PARTS LIST
BANDSAW
No. Part No. Description Qty.
108 BA1411-1108 Pointer 1
109 BA1411-1109
Flange Screw,
M5x6
1
110 BA1411-1110 Table Knob, M10 2
111 BA1411-1111 Hex Bolt, M10x50 2
112 BA1411-1112 Hex Bolt, M8x80 1
113 BA1411-1113 Nut, M8 1
114 BA1411-1114ASM
Miter Gauge
Assembly
1
115 BA1411-1115
Socket Head Cap
Screw, M8x25
2
116 BA1411-1116 Lock Washer, 8mm 2
117 BA1411-1009
Flat Washer, 8mm
x 30
2
118 BA1411-1118 Steel Ball, 8mm 1
119 BA1411-1119 Spring 1
120 BA1411-1120 Set Screw, M10x10 1
121 BA1411-1121
Set Screw, M8-
1.0x35
4
122 BA1411-1122
Micro-Adjustment
Knob
4
123 BA1411-1123
Quick-Release
Handle
1
124 BA1411-1124 Cord Clamp 1
125 BA1411-1125
Phillips Head
Screw, M5x12
1
126 BA1411-1126 Lock Nut, M4 2
127 BA1411-1127
Flat Washer, 5mm
x 12
4
128 BA1411-1128 Ball Bearing, 608ZZ 4
129 BA1411-1129
Roller Bearing Cam
Shaft
4
No. Part No. Description Qty.
130 BA1411-1130 Set Screw, M5x10 1
131 BA1411-1131
Upper Tension
Block
1
132 BA1411-1132
Flat Washer, 10mm
x 20
1
133 BA1411-1133 Tension Lever 1
134 BA1411-1134
Flat Washer, 8mm
x 18
6
135 BA1411-1135 Bushing 1
136 BA1411-1136
Socket Head
Button Screw,
M8x20
1
137 BA1411-1137 Bushing 1
138 BA1411-1138 Hex Bolt, M8x40 2
139 BA1411-1139 Lock Nut, M8 2
140 BA1411-1140 Tension Arm 4
141 BA1411-1141 Pivot Arm 1
142 BA1411-1142 Lock Washer, 8mm 2
143 BA1411-1136
Socket Head
Button Screw,
M8x20
2
150 BA1411-1150 Tension Post 1
151 BA1411-1151 Set Screw, M5x5 1
152 BA1411-1152
Phillips Head
Screw, M5x12
1
153 BA1411-1019
Toothed Washer,
5mm
1
154 BA1411-1154
Flat Washer, 8mm
x 18
1
155 BA1411-1155 SET SCREW, M5X8 2
25
NOTE: Not all parts may be available for purchase. Parts and accessories that wear
down over the course of normal use are not covered under the warranty.

Wen BA1411 Specifications

General

Brand	Wen
Model	BA1411
Category	Saw
Language	English
