KNOW YOUR BAND SAW
TOOL PURPOSE
Band saws are used to cut wood. Refer to the following diagrams to become familiarized with all the parts and
controls of your band saw. The components will be referred to later in the manual for assembly and operation
instructions.
10
Tension Knob
Light Switch
Power Switch
Locking Fence
Fence Lock
Dust Collection Drawer
Upper Housing Knob
Blade Guard Adjustment Knob
Blade Guard
Blade Bearing Adjustment Knob
Blade Tension Adjustment Knob
Lower Housing Knob
Miter Gauge
Tension Release Lever
Blade Tracking Adjustment Knob
Table Bevel Lock
Lower Spindle Tracking Adjustment Knob
Dust Port
Capacitor Box
Motor
