Wen BA1487 User Manual

EXPLODED VIEW & PARTS LIST
22
No. Part No. Description Qty.
1 3966-001 Socket head screw 1
2 3966-002 Flat washer 1
3 3966-003 Blade tension knob 1
4 3966-004 Screw 1
5 3966-005 Bushing 1
6 3966-006 Retaining ring 1
7 3966-007 Frame cap 1
8 3966-008 Hex nut 2
9 3966-009 Tension bracket 1
10 3966-010 Spring 1
11 3966-011 Nut 1
12 3966-012 Connecting plate 1
13 3966-013 Bolt 1
14 3966-014 Hex head bolt 3
15 3966-015 Flat washer 6
16 3966-016 Guide rod 3
17 3966-017 Nut 1
18 3966-018 Lock nut 3
19 3966-019 Blade tension pointer 1
20 3966-020 Bolt 1
21 3966-021 Retaining ring 2
22 3966-022 Shaft 1
23 3966-023 Guide plate 2
24 3966-024 Pulling plate 1
25 3966-025 Hex head bolt 4
26 3966-026 Flat washer 8
27 3966-027 Hex nut 4
28 3966-028 bevel block 1
29 3966-029 Shaft 1
30 3966-030 Ball bearing 4
31 3966-031 Retaining ring 4
32 3966-032 Upper wheel 2
33 3966-033 Retaining ring 2
34 3966-034 Tyre 2
35 3966-035 Blade 1
No. Part No. Description Qty.
36 3966-036 Upper cover 1
37 3966-037 Viewing window 1
38 3966-038 Window case 1
39 3966-039 Lower cover 1
40 3966-040 Lock nut 2
41 3966-041 Bushing 2
42 3966-042 Socket head screw 2
43 3966-043 Nut 1
44 3966-044 Flat washer 1
45 3966-045 LED driver 1
46 3966-046 Socket head screw 1
47 3966-047 Led switch box 1
48 3966-048 Switch cover 1
49 3966-049 Pan head screw 2
50 3966-050 LED switch 1
51 3966-051 Serrated washer 2
52 3966-052 Pan head screw 2
53 3966-053 Switch box 1
54 3966-054 Connecting terminal 3
55 3966-055
Thread forming
screw
1
56 3966-056 Main switch 1
57 3966-057 Pan head screw 2
58 BA1487-058 Frame 1
59 3966-059 Nut 1
60 3966-060 Flat washer 1
61 3966-061 Bushing 1
62 3966-062 Flat washer 1
63 3966-063 Brush 1
64 3966-064 Carriage blot 1
65 3966-065 Hex nut 1
66 3966-066 Spindle pulley 1
67 3966-067 Socket head screw 3
68 3966-068 Drawer handle 1
69 3966-069 Dust drawer 1
