EXPLODED VIEW & PARTS LISTEXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
206 3966-206 Lock block 1
207 3966-207 Lock handle 1
208 3966-208 Shaft 1
209 3966-209 Guide rail cap 1
210 3966-210 Guide rail 1
211 3966-211 Guide rail cap 1
212 3966-212 Flat washer 8
213 3966-213 Socket head screw 8
214 3966-214 Long brace 2
215 3966-215 Leg 4
216 3966-216 Hex nut 8
217 3966-217 Flat washer 8
218 3966-218 Carriage blot 8
219 3966-219 Short brace 2
220 3966-220 Push stick 1
No. Part No. Description Qty.
221 3966-221 Hook 1
222 3966-222 Hex nut 1
223 3966-223 Rack 1
224 3966-224 Pan head screw 2
225 3966-225 Spanner 1
226 3966-226 6mm hex wrench 1
227 3966-227 5mm hex wrench 1
228 3966-228 4mm hex wrench 1
229 3966-229 3mm hex wrench 1
230 3966-230 Sliding bar 1
231 3966-231 Locking knob 1
232 3966-232 Centre pin 1
233 3966-233 Support block 1
234 3966-234 Socket head screw 1
235 3966-235 Locking knob 1
NOTE: Not all parts may be available for purchase. Parts and accessories that wear
down over the course of normal use are not covered under the warranty.
