Wen CT1272 User Manual

EXPLODED VIEW & PARTS LIST
26
NO. PART NO. DESCRIPTION QTY.
1 CT1272-001 Right Handle 1
2 CT1065-002 Power Cord Clamp 1
3 CT1065-003
Self-tapping Screw,
ST4x16
14
4 CT1272-004 Capacitor, 0.47µf 1
6 CT1065-006 Trigger Spring 2
7 CT1065-007 Power Switch 1
8 CT1065-008 Plunge Release Button 1
9 CT1065-009
Plunge Release Button
Spring
1
10 CT1272-010 Left Handle 1
11 CT1065-011 Power Cord 1
12 CT1065-012
Power Cord Strain
Relief
1
13 CT1272-013
Self-tapping Screw,
ST4x20
3
14 CT1065-014
Plunge Release Linkage
Arm
1
15 CT1065-015 Trigger 1
16 CT1272-016 Speed Control PCB 1
17 CT1065-017 Bearing, 6001ZZ 1
18 CT1272-018 Rotor 1
19 CT1065-019 Bearing, 698ZZ 1
20 CT1065-020 Rotor Bearing Bushing 1
21 CT1272-021 Magnet Ring 1
23 CT1065-023 Motor Dust Shield 1
24 CT1065-024 Flat Washer, 5mm 4
25 CT1272-025
Self-tapping Screw,
ST5x68
2
26 CT1272-026 Stator 1
28 CT1065-028 Motor Housing 1
29 CT1065-029 Carbon Brush Cap 2
30 CT1065-030 Brush Holder 2
31 CT1272-031 Carbon Brush 2
32 CT1065-032
Self-tapping Screw,
ST4x11
2
33 CT1065-033 Screw, M5x45 4
34 CT1272-034 Magnetic Cover 1
35 CT1272-035
Self-tapping Screw,
ST3x12
2
NO. PART NO. DESCRIPTION QTY.
36 CT1065-036 Motor Housing Cover 1
37 CT1065-037 Spindle Lock Sleeve 1
38 CT1272-038 Gearbox 1
39 CT1065-039 Depth Selector 1
40 CT1065-040 Depth Selector Switch 1
41 CT1065-041
Depth Selector Switch
Spring
1
42 CT1065-042 Depth Selector Cover 1
43 CT1065-043 Screw, M5x8 2
44 CT1065-044 Bearing Housing 1
45 CT1065-045 Bearing, 6002zz 1
46 CT1065-046 Bearing Housing Cover 1
47 CT1065-047 Spring Washer 5mm 2
48 CT1065-048 Screw, M5x16 2
49 CT1065-049 Screw, M4x8 3
50 CT1272-050 Depth Scale Plate 1
51 CT1065-051 Screw M5x8 1
52 CT1065-052 Connecting Shaft 1
53 CT1065-053 Dust Port 1
55 CT1065-055 Screw, M4x14 6
56 CT1065-056 Locating Pin 1
57 CT1065-057
Depth Selector Locating
Pin Spring
1
58 CT1065-058 Steel Ball, Ø3mm 1
59 CT1065-059 Roller Pin 1
60 CT1065-060 Bevel Locking Knob 2
61 CT1065-061 Spindle Lock Spring 1
62 CT1065-062 Bevel Guide Plate, Front 1
63 CT1065-063 Spindle Lock 1
64 CT1065-064
Rail Adjustment Cam
Knob
2
66 CT1065-066 Rail Locking Plate Knob 1
67 CT1065-067 Reset Spring Spacer 1
68 CT1065-068 Rail Adjustment Cam 2
69 CT1065-069
Rail Anti-Kickback Cam
Knob
1
70 CT1065-070 Plunge Return Spring 1
72 CT1065-069
Plunge Return Spring
Rod
1
73 CT1065-073 Locating Rod Spacer 1

Wen CT1272 Specifications

General

Brand	Wen
Model	CT1272
Category	Saw
Language	English
