27
NOTE: Parts that wear down over the course of normal use (like saw blades, carbon brushes, etc.)
are not covered by the two-year warranty.
EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
74 CT1065-074 Base 1
75 CT1065-075 Bevel Guide Plate, Rear 1
76 CT1065-076 Bearing, 607zz 1
77 CT1065-077 Gear Assembly 1
78 CT1065-078 Depth Locking Knob 1
79 CT1065-079
Self-tapping Screw,
ST2.5x10
1
80 CT1065-080 Knob 1
81 CT1065-081 Depth Indicator Frame 1
82 CT1065-082
Depth Indicator Rail
Adjustment Button
1
83 CT1065-083 Locating Spring 1
84 CT1065-084
Depth Indicator Frame
Base
1
85 CT1065-085
Self-tapping Screw,
ST3x6
2
86 CT1065-086 Bevel Pointer 1
87 CT1065-087 Depth Locking Nut 1
88 CT1272-088 Inner Blade Cover 1
89 CT1272-089 Inner Flange 1
90 CT1272-090 Blade 1
91 CT1272-091 Outer Flange 1
92 CT1272-092 Arbor Screw 1
NO. PART NO. DESCRIPTION QTY.
93 CT1272-093 Outer Blade Cover 1
95 CT1065-095 Screw, M6x8 2
96 CT1065-096
Self-tapping Screw,
ST4x34
1
97 CT1065-097
Self-tapping Screw,
ST4x25
1
98 CT1065-098 Rail Anti-Kickback Cam 1
99 CT1065-099 Cam Reset Spring 1
100 CT1065-100
Self-tapping Screw,
ST4x10
1
101 CT1065-101 Rail Locking Plate 1
102 CT1065-102
Self-tapping Screw,
ST4x18
1
103 CT1065-103 Roller Pin 1
104 CT1065-104
Rail Locking Plate
Spring
1
105 CT1065-105 Roller Pin 1
106 CT1065-106 Rail Locking Plate Body 1
107 CT1065-107 Roller Pin 1
108 CT1065-108 Flat Washer, 6mm 2
109 CT1272-109 Block 1
110 CT1272-110 Screw, M4x6 2
N.P. CT1065-109 Dust Port Adapter 1
To Next Page
