CONTENTSSPECIFICATIONS
3
Model Number GN4500
Surge (Starting) Wattage 4500 Watts
Rated (Running) Wattage 3600 Watts
Rated Voltage 120V AC
Rated Amperage 30A
Phase Single
Frequency 60Hz
Product Weight 97.9 lbs (without wheel kit), 104.5 lbs (with wheel kit)
Product Dimensions 23-1/4 in. × 18 in. × 18-3/4 in.
GENERATOR
Engine Type
4 stroke, OHV, single cylinder with forced air cooling
system
Engine Displacement 212cc
Fuel Tank Capacity 4 US gallons (15 L), 87 octane minimum
Oil Capacity 20.3 fl. oz. (0.6 L)
Half-Load Run Time 13 hours
Lubrication System Splash
Spark Plug Type NGK BP7ES/Torch F7TC
Spark Plug Gap 0.7 - 0.8 mm (0.028 - 0.031 in.)
Spark Plug Torque
½ - ¾ turn after gasket contacts base
or 15 ft-lbs (20.34 Nm)
ENGINE
Rated output determined by PGMA Standard G300
