EXPLODED VIEW & PARTS LIST
ENGINE PARTS LIST - CONTINUED
No. Part No. Description Qty.
52 GN4500-152 Bolt, M6x28 1
53 GN4500-153 Flywheel Assembly 1
54 GN4500-154 Recoil Starter Fan 1
55 GN4500-155 Recoil Starter Cup 1
56 DF475-155 Nut, M14 1
57 GN4500-157 Ignition Coil Assembly 1
58 DF475-157 Bolt, M6x25 2
59 GN4500-159
Gasket, Carburetor
Insulator
1
60 DF475-159 Carburetor Insulator 1
61 DF475-160 Gasket, Carburetor 1
62 GN4500-162 Gasket, Air Filter 1
63 DF475-162 Governor Rod 1
64 DF475-163 Throttle Return Spring 1
65 GN4500-165
Recoil Starter
Assembly
1
N.P. GN4500-165.1 Recoil Starter 1
66 GN4500-166
Upper Shroud
Assembly
1
67 GN4500-167 Air Filter Assembly 1
N.P. GN4500-167.1 Air Filter Element 1
68 DF475-167 Breather Tube 1
69 GN4500-169 Clip 1
70 DF475-169 Governor Spring 1
71 GN4500-171
Oil Level Switch
Amplifier
1
72 DF475-171 Dipstick Assembly 1
73 DF475-175
Rocker Arm Adjuster
Assembly
2
NOTE: Replacement parts can be purchased from wenproducts.com, or by calling our customer service at
(800) 232-1195, M-F 8-5 CST. Parts and accessories that wear down over the course of normal use are not
covered by the two-year warranty. Not all parts may be available.
N.P. = Not Pictured
