EXPLODED VIEW & PARTS LIST
GENERATOR PARTS LIST
No. Part No. Description Qty.
1 GN4500-001 Alternator Assembly 1
2 DF475-002 Motor Stand 1
3 GN4500-003
Clip, Fuel Line,
Ø11.5mm
1
4 GN4500-004 Clip, Fuel Line, Ø12mm 1
5 DF475-005 Nut, M8 2
6 DF475-076 Connecting Tube 1
7 GN4500-007 Frame 1
8 DF475-008 Isolator A 2
9 DF475-009 Isolator B 2
10 DF475-075 Carbon Tank Assembly 1
11 GN4500-011 Fuel Tank Assembly 1
11.1 DF475-079 Fuel Filter 1
11.2 DF475-078 Fuel Gauge 1
12 GN4500-012 Fuel Valve 1
13 DF475-073 Fuel Tank Cap Assembly 1
14 DF475-072 Paper Washer 4
15 DF475-069 Grounding Wire 1
16 GN4500-016 Engine Assembly 1
17 GN4500-017 Bolt, M8-1.0x220 1
18 DF475-018
Rotor Bolt Gasket,
Ø8.5x24x3
1
19 DF475-065 Toothed Washer, 6mm 1
20 GN4500-020 Bolt, M6x165 4
21 DF475-021 Bolt, M6x12 14
22 DF475-064 Nut, M8 10
23 DF475-023 Air Filter Bracket 1
24 DF475-024 Muffler Gasket 1
25 DF475-063 Clip, Fuel Line, Ø10mm 1
26 GN4500-026 Muffler 1
26.1 GN4500-026.1 Spark Arrestor 1
27 DF475-027 Lock Washer, 8mm 2
28 DF475-062 Bolt, M6x40 1
29 GN4500-029 Control Panel Assembly 1
No. Part No. Description Qty.
29.1 GN4500-029.1 Engine Switch 1
29.2 GN4500-029.2 Multi-meter 1
29.3 GN4500-029.3
NEMA 5-20R 120V 20A
Duplex Receptacle
2
29.4 GN4500-029.4 AC Breaker, 20A 2
29.5 GN4500-029.5
NEMA TT-30R 120V
30A RV Receptacle
1
29.6 GN4500-029.6
NEMA L5-30R 120V
30A Receptacle
1
29.7 GN4500-029.7 Main Breaker 1
29.8 GN4500-029.8 Grounding Nut 1
30 DF475-061 Clip, Fuel Line, Ø9.5mm 1
31 DF475-050 Muffler Bracket 1
32 GN4500-032 Foot 4
33 DF475-033
Automatic Voltage
Regulator
1
34 DF475-034 Bolt, M5x16 1
35 DF475-035 Bolt, M5x12 7
36 DF475-036 Fuel Tank Washer 4
37 DF475-037 Bolt, M6x25 4
38 DF475-038 Generator End Cover 1
39 DF475-060 Clip, Fuel Line, Ø7.5mm 1
40 DF475-058
Breather Valve
Assembly
1
41 DF475-057
Connecting Tube (Fuel
Tank)
1
42 DF475-077 Dustproof Cover 1
43 GN4500-043 Damper, Fuel Tank 1
44 DF475-052 Damper 1
45 DF475-045 Nut, M6 1
46 DF475-046 Bolt, M8x16 2
47 DF1100-006 Lock Washer, 5mm 1
45 DF475-045 Nut, M6 1
46 DF475-046 Bolt, M8x16 2
47 DF1100-006 Lock Washer, 5mm 1
