Wen MM1214 User Manual

32
TABLE OF CONTENTS
Specifications ........................................................................................... 2
Introduction ............................................................................................. 3
General Safety Rules ................................................................................ 4
Specific Safety Rules for Your Miter Saw ................................................. 6
Electrical Information ............................................................................... 8
Unpacking & Transportation ....................................................................9
Know Your Miter Saw ............................................................................ 10
Assembly & Adjustments ....................................................................... 12
Operation ............................................................................................... 19
Maintenance ........................................................................................... 21
Troubleshooting Guide ...........................................................................22
Exploded View & Parts List .................................................................... 23
Warranty Statement ...............................................................................27
SPECIFICATIONS
Model Number MM1214
Motor 120V, 60Hz, 15A
Laser Type 650 nm, <1 mW
Laser Class II
No-Load Speed 3800 RPM
Blade Part Number MM1214B
Blade Size 12" (305mm) TCT
Arbor Size 1" (25.4mm)
Kerf 2.8mm
Teeth 60T
Miter Table Angles 0° - 45° Left & Right
Bevel Cut Angles 0° - 45° Left & Right
Positive Miter Stops 0°, 15°, 22.5°, 30°, and 45° Left & Right
Cutting Capacity
0° Miter, 90° Bevel 3-1/2" x 13-3/8"
45° Miter, 90° Bevel 3-1/2" x 9-1/2"
0° Miter, 45° Bevel 2-1/8" x 13-3/8"
45° Miter, 45° Bevel 2-1/8" x 9-1/2"
Weight 61 lbs
Product Dimensions 27" x 35" x 20"
Replacement blades (Part MM1214B), carbon brushes (Part MM1214-114),
and additional blades can be purchased from wenproducts.com.

Wen MM1214 Specifications

General

Brand	Wen
Model	MM1214
Category	Saw
Language	English
