REPLACEMENT PARTS LIST (CONTINUED)
3-UNIT STORAGE CART
Item Qty Description Item Qty Description
1 1 Channel, caster, right-hand (with decal) 10 1 Tube, back frame
2 1 Channel, caster, left-hand 11 2 Bracket, pivot
3 2 Caster, swivel 12 6 Bolt, carriage, 5/16 - 18 x 2"
4 2 Caster, rigid 13 2 Strap, brace
5 12 Bolt, carriage, 5/16 - 18 x 5/8" 14 2 Angle, brace
6 30 Nut, lock, 5/16 - 18 15 4 Capscrew, 5/16 - 18 x 1"
7 2 Post assembly, upright 16 12 Washer, flat, 5/16"
8 1 Tube, cross 17 4 Capscrew, 5/16 - 18 x 1-3/4"
9 4 Capscrew, 5/16 - 18 x 2 - 1/4"
