26
REPLACEMENT PARTS LIST (CONTINUED)
6 AND
8-UNIT STORAGE CART
Item Qty Description Item Qty Description
1 2 Caster, swivel 8 1 Lock assembly, unit
2 2 Channel, caster 9 1 Tube, cross
3 16 Bolt, carriage, 5/16 -18 x 3/4" 10 2 Upright assembly
4 28 Nut, lock, 5/16 - 18 11 2 Caster, rigid
5 8 Bolt, carriage, 5/16 - 18 x 2-1/4" 12 2 Brace, center
6 4 Capscrew, 5/16 - 18 x 2" 13 16 Washer, lock, 5/16"
7 2 Washer, flat, 5/16"
To Next Page
