REPLACEMENT PARTS LIST (CONTINUED)
GUARD RAILS
48
Item Qty Description Item Qty Description
1 2 Upright Weldment 9 4 Bolt, carriage, 5/16 - 18 x 3-1/4"
2 2 Lower Bracket Weldment 10 6 Nut, lock, 5/16 - 18
3 2 Bolt, tab, 3/8-16 11 1 Rail, chair [*]
4 2 Handle, tee 12 2 Rail, guard [*]
5 2 Plug, 1-1/2" square 13 1 Railing, In-Fill Panel
8 2 Capscrew, 5/16 - 18 x 3-1/2" 14 4 Plug, 1-1/8" square
[*] Indicates rail length on order.
