WEST 8800 - 4 Configuration level; 4.1 Configuration survey

4 Configuration level
4.1 Configuration survey
Adjustment:
w
The configuration can be adjusted by means of keys ÈÌ .
w
Transition to the next configuration is by pressing key Ù .
w
After the last configuration of a group, donE is displayed and followed by
automatic change to the next group
Return to the beginning of a group is by pressing the Ù key for 3 sec.
Configuration level
8800 process controller 29 Configuration survey
ConF Configuration level
È
Ì
Cntr
Control and self-tuning
InP.1
Input 1
InP.2 Input 2 InP.3
Input 3
Lim
Limit value functions
OUt.1 Output 1 OUt.2 Output 2 OUt.3 Output 3 OUt.4 Output 4 Out.5 Output 5 Out.6 Output 6 LOGI Digital inpu ts Othr Display, operation, interface
SP.Fn I.Fnc I.Fnc I.Fnc Fnc.1 O.Act
See output 1
O.tYP O.tYP
See output 1 See output 1
L_r bAud
C.tYP StYP StYP S.Lin Src.1 Y.1 O.Act O.Act SP.2 Addr
C.Fnc S.Lin Corr S.Typ Fnc.2 Y.2 Y.1 Y.1 SP.E PrtY
C.dif Corr In.F Corr Src.2 Lim.1 Y.2 Y.2 Y.2 dELY
mAn In.F Fnc.3 Lim.2 Lim.1 Lim.1 Y.E dp.Ad
C.Act Src.3 Lim.3 Lim.2 Lim.2 mAn bc.up
FAIL HC.AL dAc.A Lim.3 Lim.3 C.oFF O2
rnG.L LP.AL LP.AL dAc.A dAc.A m.Loc Unit
rnG.H dAc.A HC.AL LP.AL LP.AL Err.r dP
CYCL HC.SC HC.AL HC.AL Pid.2 LEd
tunE P.End HC.SC HC.SC I.Chg dISP
Strt FAi.1 P.End P.End di.Fn C.dEl
FAi.2 FAi.1 FAi.1
FAi.3 FAi.2 FAi.2
FAi.3 FAi.3
OuT.0 OuT.0
Out.1 Out.1
O.Src O.Src
